HEAVY-DUTY BUS BAR BOX (BF433)
0.00฿
Out of stock
ต้องการใบเสนอราคาติดต่อฝ่ายขายได้ที่ Line: @gtmmarine
- Facebook page: GTM MARINE
Heavy-Duty Module Design Bus Bar Box with 2 x M10 Terminal Studs & 6 x M5 Screws
*Clamshell Package
*BF433-Heavy-Duty Module Design Bus Bar Box with 2 x M10 Terminal Studs & 6 x M5 Screws
Features
- Highest amperage rated bus bar (300A) with M10 terminal studs
- Module box design for easy wiring configurations
- Glass Fiber reinforced Nylon base and enclosure ensures great mechanical strength and durability
- Removable windows for unobstructed wiring
- Blank write-on space on the top allows easy labeling for each branch
Specification
- Base & Cover Material | Nylon, Glass Fiber reinforced
- Bus Material | Brass, Nickel plated
- Max Operating Voltage | DC 48V
- Max Continuous Amp | 300A
- Terminal Stud Size | 2 x M10 (3/8″)
- Screw Size | 6 x M5 (3/16″)
- Dimensions (L x W x H) | 138 x 69 x 44.5mm
