ALUMINUM SWITCH PANEL WITH CIG. LIGHT & USB CHARGER SOCKETS (SP3234P)

0.00฿

Out of stock

ใบเสนอราคาติดต่อฝ่ายขายได้ที่ Line id : @gtmmarine

    Categories: ,

    Water-resistant Switch Panel with USB Charger and Cig. Lighter Socket (Dark Gray)

    *SP3234P-Water-resistant Switch Panel with USB Charger and Cig. Lighter Socket (Dark Gray)
    *YIS exclusive backlight modules
    *IP66 rated
    Coming with the IP66 C-7 sealed rocker Switches, these switch panels can withstand even severer weather conditions than the C-6 Water-resistant Switch Panel. SP32xx series are the only aluminum switch panels in the market with backlight modules for labels.

    Features

    • New modern and compact panel design (15% smaller than SP30xx series)
    • Backlight modules for labels, allowing easy operation in darkness
    • IP66–protect against strong water jets
    • Push-reset circuit breakers with rubber boots
    • Illuminated (LED) C-7 rocker switches with dual voltage rating (12V / 24V)
    • Watertight mounting gasket included
    • Square shaped label stickers (30pcs) allow vertical or horizontal installation
    • Dual Sockets: 1 DC Cig. Lighter Socket & 1 USB Charger Socket

    Specification

    • Faceplate | 0.1″(2.54mm) Coated Aluminum Alloy
    • Circuit Protection | Circuit Breakers
    • Switch Ratings | 20A @ DC 12V / 10A @ DC 24V (Dual Voltage)
    • Panel Rating | Max Cumulative Amp: 45A (Max possible Amperage for each panel is determined by the lower of total switches ratings or the Max Cumulative Amperage listed above)
    • Product Dimensions (W x H) | 114 x 191mm
    • Mounting Depth | 75mm
    • Panel Cut-out (W x L) | 96 x 166mm

    Certification

    SP3234P C-7 Aluminum Water-resistant Switch Pane
